Learning SQL Notes #1

• Introduction to Databases
  • More about Relational Databases
  • Find Databases
  • Find a Table
  • Create a Table
  • Add a Row
  • Change a Cell
  • Delete a Row
  • Table Overview
  • Show Tables
  • Drop a Table
  • Export to XML
• Table Creation (CH. 2)
  • 1 Design
  • 2 Refinement
  • 3 Building SQL Schema Statements

Introduction to Databases

• SQL was initially created to be the language for generating, manipulating, and retrieving data from relational databases.
• A database is a set of related information.
• Database systems are computerized data storage and retrieval mechanisms.
• Nonrelational Database Systems:
  • In a hierarchical database system, for example, data is represented as one or more tree structures. The hierarchical database system provides tools for locating a particular customer’s tree and then traversing the tree to find the desired accounts and/or transactions. Each node in the tree may have either zero or one parent and zero, one, or many children.
  • Network database system exposes sets of records and sets of links that define relationships between different records.
• Data can be represented as sets of tables. Rather than using pointers to navigate between related entities, redundant data is used to link records in different tables: relational model.

More about Relational Databases

1. Now columns/rows are constrained due to physical limit or maintainability;
2. Primary key includes information that uniquely identifies a row in that table;
   1. If more than one column, then compound key;
   2. If select, say, first name, then it is a natural key;
   3. If select an id, then it is a surrogate key;
   4. NEVER be allowed to change!
   5. Possible error:

      ERROR 1062 (23000): Duplicate entry '1' for key 'PRIMARY'


3. More than one identifiers in a table including the primary key: foreign keys, connect the entities in different tables;
4. Make sure that there is only one place in the database that holds, say, the customer’s name; otherwise, the data might be changed in one place but not another, causing the data in the database to be unreliable. The process of refining a database design to ensure that each independent piece of information is in only one place (except for foreign keys) is known as normalization. (Think about the concept of Tidy Data in R!)
5. Two-column primary key is also possible depending on the context (CH.2);
6. Foreign key constraint limits the id to those exist in another table (CH.2); Possible error:

   ERROR 1452 (23000): Cannot add or update a child row: a foreign key constraint fails ('sakila'.'favorite_food', CONSTRAINT 'fk_fav_food_person_id' FOREIGN KEY
   ('person_id') REFERENCES 'person' ('person_id'))


7. Ways to generate primary keys:
   • Look at the largest value currently in the table and add one.
   • Let the database server provide the value for you.

   ALTER TABLE table_name MODIFY col_0 SMALLINT UNSIGNED AUTO_INCREMENT;

   set foreign_key_checks=0; /*IMPORTANT*/
   ALTER TABLE person
       MODIFY person_id SMALLINT UNSIGNED AUTO_INCREMENT;
   set foreign_key_checks=1; /*IMPORTANT*/


Find Databases

To see the see the mysql> prompt:

mysql -u root -p;

Then type show databases; to display all databases;

Find a Table

To select a table, type use table_name;;

Can do the following:

mysql -u root -p table_name;

InR, one can find it under the global environment.

Create a Table

CREATE TABLE table_name /*Create a table with name: ……*/
    (col_0 smallint;
    col_1 VARCHAR(30);
    col_2 timestamp;
    CONSTRAINT pk_col_0 PRIMARY KEY (col_0) /*set col_0 as primary key*/
    ); /*The most basic method to create a database*/

R codes:

df <- data.frame()
# x1 = c(7, 3, 2, 9, 0),
# x2 = c(4, 4, 1, 1, 8),
# x0 = c(5, 3, 9, 2, 4)
# Primary key can only be added manually

Add a Row

INSERT INTO table_name (col_0, col_1, col_2) /*The table*/
VALUES (27, 'Rdm Name', 'Acme Paper Corporation'); /*The values*/
/*The most basic method to insert a full row into a database*/

Query OK, 1 row affected$\Rightarrow$one row was added to the database

R codes:

new_row <- c(27, 'Rdm Name', 'Acme Paper Corporation')
rbind(df, new_row)

• You are not required to provide data for every column in the table unless the column cannot be NULL;
• MySQL will convert the string to a date for you as long as the format is followed;

  ERROR 1292 (22007): Incorrect date value: 'DEC-21-1980' for column 'birth_date' at row 1


Change a Cell

UPDATE table_name
/*Fix column*/  /*Insert the values*/
SET name = 'Certificate of Deposit'
WHERE col_2 = 'CD'; /*Fix row, otherwise all will be replaced*/

R codes:

df[df$col_2=='CD', "name"] <- 'Certificate of Deposit'
# Fix column, fix row

Delete a Row

DELETE ...
/*Fix column*/
FROM table_name
WHERE col_2 = 'CD'; /*Fix row, otherwise all will be deleted*/

R codes:

df[df$col_2=='CD', ] <- NULL

Table Overview

DESC favorite_food;

R codes:

str(df)
summary(df)
glimpse(df)

Describe the table.

Show Tables

show tables

Drop a Table

drop table xxx

Export to XML

Type the following in CMD:

mysql -u lrngsql -p --xml bank

OR

SELECT * FROM table_name
FOR XML AUTO, ELEMENTS /*IMPORTANT*/

No easy way to do so in R.

Table Creation (CH. 2)

1 Design

What info is needed? Make a list.

2 Refinement

1. Compound objects need to be separated into multiple columns, including names or address;
2. If a column is a list containing zero, one, or more independent items, we need another table;
3. Need primary key column(s) to guarantee uniqueness.

3 Building SQL Schema Statements

Another type of constraint called a check constraint constrains the allowable values for a particular column. A check constraint to be attached to a column definition.

eye_color CHAR(2) CHECK (eye_color IN ('BR','BL','GR'))

Possible error:

ERROR 1265 (01000): Data truncated for column 'eye_color' at row 1

MySQL does provide another character data type called enum that merges the check constraint into the data type definition.

eye_color ENUM('BR','BL','GR')

R codes:

Enum <- function(...) {

  ## EDIT: use solution provided in comments to capture the arguments
  values <- sapply(match.call(expand.dots = TRUE)[-1L], deparse)

  stopifnot(identical(unique(values), values))

  res <- setNames(seq_along(values), values)
  res <- as.environment(as.list(res))
  lockEnvironment(res, bindings = TRUE)
  res
}

FRUITS <- Enum(APPLE, BANANA, MELON)

See https://stackoverflow.com/questions/33838392/enum-like-arguments-in-r for further details.

After processing the create table statement, the MySQL server returns the message “Query OK, 0 rows affected,” which tells me that the statement had no syntax errors.
